SAI OVISLINK KRYPTON C60 CHASIS 60 KVA TRIFASICO SIN BATERIAS

Capacity: 10.200kva:

Main input:

Input voltage: pulgadas380v — 400v — 415v(line to line)220v — 230v — 240v(line to neutral)pulgadas:

Input frequency: 50.60hz:

Power factor: >0.99:

Input voltage window — 40%~+25%:

Frequency window: 40.70hz:

Battery:
battery voltage: ±240vdc:

Charger power: 20%*power:

Charger voltage precisión: 1%:

Bypass:
bypass voltage: pulgadas380v — 400v — 415v — three phase220v — 230v — 240v — one phasepulgadas:

Bypass voltage window — 20% - +15% — full load — settable:

Bypass overload capabiltiy: 125% — long time operatión:

: 125%< load <130% — last for more than 1 hour:

: 130%

: >1000% — last for more than 100ms:

Output:
output voltage: pulgadas380v — 400v — 415v — three phase220v — 230v — 240v — one phasepulgadas:

Voltage precisión: ±0.5% (balance load) -±1% (unbalance load):

Voltage thd(total harmonic distortión): thd<1%(linear load) -thd<5%(nonlinear load):

Power factor: 0.8:

Phase tolerance: 120°±0.5° (balance and unalance load):

Crest factor: 3:1:

Overload capabiltiy: 105% -long time operatión:

: 110% — transfer to bypass after 1hour:

: 125% — transfer to bypass after 10 minutes:

: 150% — transfer to bypass after 1 minute:

: >150% — transfer to bypass after 200ms:

System:
system efficiency: normal mode: 95%:

: eco mode: 99%:

Battery mode efficiency: 95%:

Display: lcd+led — touch screen and keyboard:

Ip class: ip20:
interface (communicatión ports ): rs232 -rs485 -dry contacts -snmp card -epo -generator
interface:
installatión — connectión: top or bottom cable connectión:

Operatión temperature: 0.40:

Storage temperature — 25~70:

Relative humidity: 0.95% (non — comdensing):

Noise(db): <55db:
weight(kg): 6 — module cabinet: rm060.10 — rm090.15 — rm120.20:
: 150kg:
: 10 — module cabinet: rm100.10 — rm150.15 — rm200.20:
: 180kg:
: pm10: 10kva: 20kg:

: pm15: 15kva: 21kg:

: pm20: 20kva: 22kg:

Dimensión(w*d*h)(mm): 6 — module cabinet: 600*900*1600:

: 10 — module cabinet: 600*900*2000:

: module: 400*600*133 (10kva — 15kva — 20kva):
